150 KW Top Feed Electric Vibro Float Engineering Construction Vibro machine

Product Details:

Place of Origin:	China
Brand Name:	BVEM
Certification:	ISO 9001:2015
Model Number:	BJV150E-377

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	wooden case
Delivery Time:	15 work days
Payment Terms:	L/C, T/T, MoneyGram
Supply Ability:	600 sets per year

Contact Now

All Products

Vibroflotation Equipment (10)

Vibro Float (10)

Vibroflotation Compaction (10)

Sheet Pile Vibro (10)

Vibro Hammer Machine (10)

Vibro Replacement Device (10)

Vibroflot Drive Pile Machine (10)

Industrial Data Logger (5)

Vibro Stone Columns (10)

Control Panel Cabinet (4)

Vibroflot Parts (6)

Detailed Product Description

Product Name:	Vibrator Equipment	Power:	150 KW
Max Amplitude:	19 Mm	Vibration Power:	180-276 KN
Rated Current:	290 A	Outer Diameter:	377 Mm
Highlight:	vibro tamper , vibro piling equipment

150 kW top feed vibroflot equipment for vibroflotation construction by vibro replacement

Vbro-replacement techniques

Jet water and vibrate by vibroflot to form holes. Fill in pile holes by section with solid filling materials such as gravel (cobble) etc., to finally form composited foundation.

Boring

By vibration and the flushing of water and/or air, the vibroflot penetrates to the designed depth.

Backfill

Fill stones into the bore-hole, and compact section by section up to the ground according to the requirements of compaction current and the sectional compaction length.

The Top Feed Electric Vibroflot Spec.
Type	Power (kW)	Rated current(A)	Max rotation speed(rpm)	Max amplitude (mm)	Vibration power(kN)	Weight (kg)	Outer diameter(mm)	Length(mm)
BJV75E-377	75	148	1450	17.5	188	1828	377	3110
BJV130E-377	130	255	1450-1800	19	180-276	1900	377	3355
BJV150E-377	150	290	1450-1800	19	180-276	2100	377	3445
BJV180E-377	180	350	1450-1800	21	180-276	2140	377	3485
