High Efficiency Compacted Pile Equipment Vibrating Floater BJV75E-377

High Efficiency Compacted Pile Equipment Vibrating Floater BJV75E-377

High Efficiency Compacted Pile Equipment Vibrating Floater BJV75E-377

Product Details:

Place of Origin: China
Brand Name: BVEM
Certification: ISO 9001:2015
Model Number: BJV75E-377

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: USD 13000-15000 SET
Packaging Details: wooden case
Delivery Time: 15 work days
Payment Terms: L/C, T/T
Supply Ability: 600 sets per year
Contact Now
Detailed Product Description
Product Name: Vibroflotation Machine Power: 75 KW
Max Amplitude: 17.5 Mm Vibration Power: 188 KN
Rated Current: 148 A Outer Diameter: 377 Mm
Working Pile Diameters: 700mm-1200mm Generate Power: 200 KVA
Highlight:

compacted pile equipment

,

vibrating floater



Electrical vibro compaction piling machine with high quality and efficiency BJV75E-377



BVEM profile (Beijing vibroflotation engineer machinery co.,ltd)



BVEM focus on vibroflotation market and formed a business platform with vibroflotation technique as core, on which there are three main business including the manufacturing and integration of vibroflotation equipment, sales and service for vibroflotation equipment and foundation improvement construction undertaking. BVEM is the largest manufacturer of electrical vibroflot in Asia and one of the authors of Chinese vibroflot manufacturing code.



The Top Feed Electric Vibroflot Spec.
Type Power
(kW)
Rated current(A) Max rotation speed(rpm) Max amplitude
(mm)
Vibration power(kN) Weight (kg) Outer diameter(mm) Length(mm)
BJV75E-377 75 148 1450 17.5 188 1828 377 3110
BJV100E-377 100 195 1450-1800 19 180-276 1880 377 3215
BJV130E-377 130 255 1450-1800 19 180-276 1900 377 3355









High Efficiency Compacted Pile Equipment Vibrating Floater BJV75E-377



1.The first one who introduced and studied vibro compact method in China
2.The first one who developed application in Chinese projects
3.Has the top experts of vibroflotation tech. and experienced construction management team
4.China first one who reserched and produced vibrators
5.China first and only one who produced the Bottom Feed Vibroflot
6.The first one who produced domestic hydraulic-driven vibrator
7.All types&models coverage:30kw-260kw
8.Editor-in-cheif of industry standards <Technical Specification of Vibroflotation Method in Hydrauelectric and Water Resources Projects>(DL/T5214-2005)
9.Editor-in chelf of industry standrds <Electrical Deep Vibrator>(DL/T 1557-2016)
10.China first one who developed vibroflotation application in variety of industry(thermal power,hydraulic power, petrochemical, highway,rail, port etc.)
11.Cooperate with DI and support to formulate the design and construction scheme
