High Efficient Construction Vibro Tamper Stone Column Soil Improvement BJV150E-426

Product Details:

Place of Origin:	China
Brand Name:	BVEM
Certification:	ISO 9001:2015
Model Number:	BJV 150 E-426

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	WOODEN CASE
Delivery Time:	15 WORK DAYS
Payment Terms:	L/C, T/T
Supply Ability:	600 SETS PER YEAR

Contact Now

All Products

Vibroflotation Equipment (10)

Vibro Float (10)

Vibroflotation Compaction (10)

Sheet Pile Vibro (10)

Vibro Hammer Machine (10)

Vibro Replacement Device (10)

Vibroflot Drive Pile Machine (10)

Industrial Data Logger (5)

Vibro Stone Columns (10)

Control Panel Cabinet (4)

Vibroflot Parts (6)

Detailed Product Description

Product Name:	Vibro Compaction Pile	Rated Current（A）:	290
Max Rotation Speed（rpm）:	1450	Max Amplitude （mm）:	18.9
Outer Diameter（mm）:	426	Working Pile Diameters:	800-1200 Mm
Highlight:	compacted pile equipment , vibrating floater

Vibroflotation compaction equipment with efficient electrical vibrator BJV150E-426

Vibro compaction

Under the effect of vibration, the saturated sand soil liquefaction happen,which make the sand particles re-arranged and the soil interspace reduced.

Boring
By vibration and the flushing of water and/or air, the vibroflot penetrates to the designed depth.

Compaction
Compact the soil section by section up to the gound according to the requirements of the compaction current, compaction time and sectional compaction length.

The Top Feed Electric Vibroflot Spec.
Type	Power (kW)	Rated current(A)	Max rotation speed(rpm)	Max amplitude (mm)	Vibration power(kN)	Weight (kg)	Outer diameter(mm)	Length(mm)
BJV150E-426	150	290	1450	18.9	276	2516	426	3023
BJV180E-426	180	350	1450	18.9	276	2586	426	3100

Vibro replacement
Jet water and vibrate by vibroflot to form holes. Fill in pile holes by section with solid filling materials such as gravel (cobble) etc., to finally form composited foundation.

Boring
By vibration and the flushing of water and/or air, the vibroflot penetrates to the designed depth.

Backfill
Fill stones into the bore-hole, and compact section by section up to the ground according to the requirements of compaction current and the sectional compaction length.

High Efficient Construction Vibro Tamper Stone Column Soil Improvement BJV150E-426

vibroflot supplier introdution

Researched and produced vibrators in power of 30KW,55KW,75KW since 1977 to 2005
Researched and produced 150kw vibrator in 2006
Researched and produced 180kw vibrator in 2009
Produced Bottom Feed Vibrator with double lock pressure bunker in 2012
Researched and produced 260kw vibrator in 2014
Researched and produced Z125 Hydraulic-driven vibrator in 2014
Lauched Vibrator performance testing equipment in 2014
