High Power Vibroflotation Compaction Machine For Vibro Piling Engineering BJV130E-426

Product Details:

Place of Origin:	China
Brand Name:	BVEM
Certification:	ISO 9001:2015
Model Number:	BJV130E-426

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	WOODEN CASE
Delivery Time:	15 WORK DAYS
Payment Terms:	L/C, T/T
Supply Ability:	600 SETS PER YEAR

Contact Now

All Products

Vibroflotation Equipment (10)

Vibro Float (10)

Vibroflotation Compaction (10)

Sheet Pile Vibro (10)

Vibro Hammer Machine (10)

Vibro Replacement Device (10)

Vibroflot Drive Pile Machine (10)

Industrial Data Logger (5)

Vibro Stone Columns (10)

Control Panel Cabinet (4)

Vibroflot Parts (6)

Detailed Product Description

Product Name:	Vibroflot Equipment	Vibration Power（kN）:	208
Weight （kg）:	2320	Outer Diameter（mm）:	426
Generator Power:	300 KVA	Working Pile Diameters:	800-1200 Mm
Highlight:	vibroflot drive pile machine , vibroflotation compaction machine

Electrical vibroflot with powerful motor used for vibro piling engineering BJV130E-426

vibroflot characteristics

The vibroflot barrel and the motor housing are made of high strength forged steel
The motor coil adopts high temperature aging film envelop, long service life and good insulation effect
Unique circulating water cooled motor structure, good heat dissipation with high efficiency
Both vibroflot and motor are imported with FAG original bearing
Double-deck vibrating head design with good resistance, easy to replace
Unique bearing oil lubrication, further improve bearing life

Vibroflot manufacturer profile (BVEM)

China first use of 75KW vibrator for the 30-meter depth sand soil treatment(three gorges project)
China first use of hydraulic vibrator for the treatment of the 240-meter chimney foundation
China first use of hydulic vibrator for the treatment of 32m depth foundation of hydraulic power station
The first one in China who treated the base of oil storage tank with a diameter of more than 60m by vibroflotation method

The Top Feed Electric Vibroflot Spec.
Type	Power (kW)	Rated current(A)	Max rotation speed(rpm)	Max amplitude (mm)	Vibration power(kN)	Weight (kg)	Outer diameter(mm)	Length(mm)
BJV130E-426	130	255	1450	17.2	208	2320	426	2963
