Industrial 180 KW Vibro Float Equipment Vibro Stone Columns Ground Improvement

Industrial 180 KW Vibro Float Equipment Vibro Stone Columns Ground Improvement

    • Industrial 180 KW Vibro Float Equipment Vibro Stone Columns Ground Improvement
    • Industrial 180 KW Vibro Float Equipment Vibro Stone Columns Ground Improvement
  • Industrial 180 KW Vibro Float Equipment Vibro Stone Columns Ground Improvement

    Product Details:

    Place of Origin: China
    Brand Name: BVEM
    Certification: ISO 9001:2015
    Model Number: BJV180E-377

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: Negotiable
    Packaging Details: wooden case
    Delivery Time: 15 work days
    Payment Terms: L/C, T/T, MoneyGram
    Supply Ability: 600 sets per year
    Contact Now
    Detailed Product Description
    Product Name: Vibro Pile Device Vibration Power: 180-276 KN
    Outer Diameter: 377 Mm Generator Power: 450 KVA
    Efficiency: High Efficiency Power: 180 KW
    Highlight:

    under water piling equipment

    ,

    vibro float equipment



    Ideal 180 kW top feed vibroflot with high efficient in stone column construction



    Vibroflot overview
    Gravel or backfill sand is filled from top of borehole
    The most commonly used vibroflotation equipment
    Used for vibro compaction and vibro replacement construction in general condition
    Economy and efficient vibro construction method



    Vibroflot Spec.
    Type BJV180E-377 BJV180E-426
    Power/kW 180 180
    Rotation speed/rpm 1450-1800 1450
    Amplitude (at Tip)/mm 21 18.9
    Centrifugal force/kN 180-276 276
    Weight /kg 2140 2586
    Diameter/mm 377 426
    Length/mm 3485 3100
    Diameter of the work pile/mm (1000-1200) (1000-1500)







    Industrial 180 KW Vibro Float Equipment Vibro Stone Columns Ground Improvement   Industrial 180 KW Vibro Float Equipment Vibro Stone Columns Ground Improvement



    BVEM profile (Beijing vibroflotation engineer machinery co.,ltd)

    BVEM focus on vibroflotation market and formed a business platform with vibroflotation technique as core, on which there are three main business including the manufacturing and integration of vibroflotation equipment, sales and service for vibroflotation equipment and foundation improvement construction undertaking. BVEM is the largest manufacturer of electrical vibroflot in Asia and one of the authors of Chinese vibroflot manufacturing code.
    With 30 years experience of vibroflotation industry, BVEM researched and developed a variety of electric vibroflots motor power from 30 kw to 260 kw. BVEM’s vibroflots has complete specification model which makes widely using of range. The quality of the equipment and performance have already achieved the domestic industry leading level. Through the application of hundreds of domestic and international projects, including the Yangtze River Three Gorges Soft Ground Treatment Project, The Hong kong-Zhuhai-Macao Bridge Project, Dubai Palm Island Project,etc, BVEM has developed to be Asia's larger electrical vibroflots equipment manufacturers, and are being highly recognized by domestic and international clients.
